PLASMA RETROFIT PACKAGES PROVIDE retrofit for EXISTING CUTTING MACHINES

ServoMecanik's retrofit packages are ideal for companies looking to provide an extra life to existing equipment through the inclusion of our ServoTouch Motion Control.

ServoMecanik's retrofit package offers standard cutting with plasma or oxy-fuel modes and a choice of production.

Using the ServoTouch motion control provides other advantages with different material types and thickness requirements easily accommodated by only changing the power source. Our genuine very simple control interface gives the user easy control of the plasma or oxy-fuel cutting process regardless of the application.

Simple CNC interface and modular system design provides easy mounting solutions with the existing equipment.

ServoMecanik's PC-based ServoTouch has been specially designed for plasma and oxyfuel flame cutting, as well as router, water jet and laser machinery. As seen below, the ServoTouch's graphic touch-screen gives the operator the flexibility to draw and nest any shapes without prior knowledge of CAD software.

Key Benefits

Easy to use - no need to hire specialized operators
Graphical menus using a touch screen
High definition 10.5" LCD screen
Cost effective
Reads standard G-code files and DXF files
Edit / Create and modify any parts
Manual and automatic operation
No need for battery backup
Support imperial and metric units
Part nesting
RS485 serial link for part upload/download (optionnal)
Display part dimensions
Manual nesting for leftover optimization
Rotation / mirror of parts or nesting

This figure shows how using simple commands (line, arc circle, rectangle), the operator can create thousands of different shapes. These shapes can then be positioned on the screen using simple joystick movements. As an examples, the diameter and center position of a circle is shown here.

The nesting of shapes on a workpiece is made in an instant using ServoMecanik's ServoTouch motion control. As shown here, you can choose to move, cope erase, rotate and set the cutting order of shapes appearing in the nest. This exclusive and innovative approach allows any shapes or DXF file to be used to optimize leftovers.

The last screen shows the execution menu, which lets the operator chose between oxy-fuel or plasma to perform the cutting task. In the case, the plasma process has been chosen. By pressing start, the ServoTouch motion control will ask the operator to enter an approximate speed, kerf and starting position of the torch on the workpiece. This process is simple and easy to learn, it makes the ServoTouch the State-of-the-art of its category.
