ServoMecanik is proud to present the MasterGraph, the new standard in CNC flame/plasma cutting system. Its unique heavy-duty and dual gantry design offer multi-torch cutting for years of trouble free service. The rugged, heavy-duty frame and rail system is equipped with rack and pinion, driven by servo-motors to enhance smooth, accurate positioning on both axis. The system is equipped with ServoMecanik's ServoTouch graphic motion control giving the operator the ability to draw and nest any shape without prior knowledge of CAD software

Key Features

• ServoTouch motion control unit
• Servo-motors with rack & pinion on both axis
• Motorized torch lifter
• Multi-process tools
• Up to 600 Amps plasma unit
• Up to 3 plasma torches
• A none touching system is used to control plasma torch height from workpiece
• Automatic pierce height adjustment
• Dual-motor drive for more precision
• Width from 4 up to 10 feet of effective cut area
• Length from 8 up to 60 feet of effective cut area
